  • Active P-Active brake with a P1000 throttle included
  • Stacked architecture keeps the footprint compact
  • Add a C-P1000 clutch for a three-pedal set
  • SHIPS FROM NEW JERSEY USA
Regular price$1,199.00
/
Great shipping rates — calculated at checkout.

%3Cp%3E%3Cstrong%3EEarn%20up%20to%20[points_amount]%20with%20this%20purchase!%3C/strong%3E%3C/p%3E
Simagic P-Active P1000-FB Bundle
Simagic P-Active P1000-FB Bundle
$1,199.00

An Active Brake and a Throttle, Ready to Go

The Simagic P-Active P1000-FB Bundle pairs a servo-driven P-Active brake with a P1000 throttle on one platform. So you get active braking without replacing your whole pedal box.

Buying the pedal alone leaves you sourcing a throttle and working out mounting. However, this bundle arrives as a working two-pedal set.

Proprietary Stacked Architecture

Simagic stacks the active pedal's components rather than laying them out flat. Therefore the unit takes less floor space than its performance would suggest.

Because the footprint is compact, the bundle suits tighter cockpits and wheel stands as well as full rigs.

Quick Pedal-Angle Adjustment

Pedal angle adjusts quickly to suit your seating position. As a result, moving between a reclined formula position and an upright GT one does not mean stripping the assembly down.

Mechanical Aesthetics

The open-frame design leaves the internals visible. So the precision components are part of how the pedal looks, not hidden behind a cover.

Built Into the Simagic Ecosystem

Everything runs through SimPro Manager alongside the rest of your Simagic hardware. In addition, the P-Active draws live telemetry for ABS, traction control, wheel slip, RPM and gear shifts.

Expanding the Simagic P-Active P1000-FB Bundle

The bundle covers brake and throttle. However, adding a C-P1000 clutch makes it a three-pedal set.

Therefore you can start here and build out later without changing platform. The P-Active itself can also be reconfigured as a throttle or clutch in software.

Why Buy From Apex Sim Racing

Apex Sim Racing is an authorized Simagic retailer in the United States. So every order ships with full US warranty coverage and US-based technical support. In short, backed by 25,000+ orders shipped.

Complete Your Setup

Add a P-Active Baseplate for a dedicated platform, or see the P-Active Pedal on its own.

P-Active pedal

  • Load cell sensor: custom 250kg dual sensors
  • Maximum pedal force: 180kg software limit
  • Sensor resolution: 16-bit
  • Full-stroke return: from 100ms
  • Servo motor: 600W rated, 4,500 RPM maximum speed
  • Power supply: DC 48V / 8.3A (max 398W)
  • Adjustments: travel, angle and position, linearity, pedal force, deadzone
  • Materials: CNC aluminum alloy, PC, rubber
  • Dimensions (L x W x H): 335.9 x 87 x 241.5 mm
  • Net weight: 6.12 kg
  • Control box: included

Bundle

  • Configuration: active brake plus P1000 throttle
  • Expansion: add a C-P1000 clutch for a three-pedal set
  • Software: SimPro Manager
  • Connectivity: PC, Simagic base

Plug & Play PC Compatible Via USB

PC and Simagic wheelbases, configured in SimPro Manager. Expands to a three-pedal set with the addition of a C-P1000 clutch module. The P-Active pedal can be reconfigured as a brake, throttle or clutch in software.
