Simagic - P1000 Sim Racing pedal set. Standard and inverted 3 pedals
P1000 Pedal Set - standard 3 pedal - Front view - Apex Sim Racing
P1000 Pedal Set Top View- Apex Sim Racing
P1000 Pedal Set - Rear View - Apex Sim Racing
P1000 Pedal Set Side View - Apex Sim Racing
P1000 Pedal Set inverted 3 pedal front view- Apex Sim Racing
P1000 Pedal Set - Apex Sim Racing - Sim Racing Products
Simagic P1000 Pedal Set inverted - hydraulic - Apex Sim Racing
Simagic  inverted loadcell P1000 Pedal Set - Apex Sim Racing
P1000 2 pedal formula hydraulic Pedal Set - Apex Sim Racing
P1000 2 pedal formula load cell Pedal Set - Apex Sim Racing

P1000 Sim Racing Pedals

Regular price
Shipping calculated at checkout.
  • Ships only within North America
P1000 Sim Racing Pedals - $489.00

Shop Pay gives you the option to pay in full at checkout, or to split your purchase into four equal, bi-weekly, interest-free installment payments. When available, Shop Pay Installments is an option for orders between 50 USD and 3,000 USD.

There are no additional charges, interest rates, or late fees, and your credit score isn't affected.

Learn more

Simagic Products only ship within North America.

Shipping Policy

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Optimize your setup with the precision-engineered Simagic P1000 sim racing pedal set. Compatible exclusively with PC systems, available in both 2 or 3 pedal configurations, with options for standard or inverted mounting.

Experience the ultimate control with either a loadcell or hydraulic brake system. Each pedal features customizable settings, including adjustable travel, spring force levels, and brake force, to tailor your driving style perfectly.

The high-resolution 12-bit sensors ensure detailed and responsive feedback. Crafted from CNC aluminum alloy, the pedals are both durable and stylish, making them an essential addition for any serious sim racer.

  • Pc Compatible Only
  • Available in 2 or 3 pedal standard mount or 3 pedal inverted mount with loadcell or hydraulic brake.
  • Haptic Compatible (Not Included)
  • Compatible with LED Sim Ray heel stop and Sim Ray Bar (Not Included)

Technical Specs Load Cell - Pedal Set

- Product Name: P1000/P1000i
- Resolution: 12-Bit (4096) [High accuracy sensor]
- USB Connection: PC / Simagic Wheelbase (Can-Bus Port)
- Adjustable Travel: Supported
- Adjustable Spring Force Level: Clutch, Brake
- Sensors:
- Throttle: Hall angle sensor
- Brake: Hall angle sensor / Loadcell sensor
- Clutch: Hall angle sensor
- Loadcell sensor: 100KG
- Haptic Pedal Reactor: Optional
- Inverted Installation: P1000i
- Pedal Plate: Anodized Aluminum Alloy
- Angle / Position Adjustment: Supported
- Adjustable Linearity: Supported
- Adjustable Brake Force: Supported
- Adjustable Deadzones: Supported
- Pedal Control Box: Included
- Building Material: CNC Aluminum Alloy
- Dimensions (Length x Width x Height):
- P1000: 334.8mm x 336mm x 267mm
- P1000i: 348mm x 489.8mm x 368.5mm
- Net Weight:
- P1000: 5.65kg
- P1000i: 7.60kg

Technical Specs Hydraulic

-Product Name: P1000-RS/P1000i-RS
12Bit (4096) [High accuracy sensor]
-USB Connection:
PC, SIMAGIC Wheelbase (Can-Bus Port)
-Adjustable Travel:
-Adjustable Spring Force Level:
Clutch, Brake
Hall angle sensor
Hall angle sensor/Loadcell sensor
Hall angle sensor
- Loadcell Sensor:
-Haptic Pedal Reactor:
-Hydraulic Cylinder:
- Inverted Installation:
-Pedal Plate:
Anodized Aluminum Alloy
-Angle/Position Adjustment:
-Adjustable Linearity:
-Adjustable Brake Force:
-Adjustable Deadzones:
-Pedal Control Box:
-Building Material:
CNC Aluminum Alloy
-Dimensions (Length x Width x Height):
334.8mm x 336mm x 267mm
348mm x 489.8mm x 368.5mm
-Net Weight:
