Compatibility: PC - 1 USB connections (include 1 - 6ft USB Cable)

Plug and play no additional software is needed

Simucube Pro & Sport, OSW, VRS, Mige Small & Large, Simucube Ultimate, Simagic Alpha, Alpha Mini

6mm Real Carbon Fiber Matte Twill Weave Plate

Mounts directly to the front of wheel base

Please confirm that this will fit your setup. The dash has enclosures + Cables that come out of the rear that will not fit certain mounts and or may need spacers to fit properly. If you are unsure please contact us

Left Side

1 - On Off Latching Toggle with Guard

1 - Apex Branded Engine Start Button

3 - MOM OFF MOM Toggles with black boot

5 - 12mm Momentary Push Buttons (Multi switch option adds a 7way multi switch to replace center push button) Up, Down, Left, Right, Push, Encoder Left & Right

Right Side

8 - 12mm Momentary Push Buttons

4 - CTS Encoders

1 - Billet aluminum Brake Bias Knob (can be used for other settings)

Compatible with

Simucube 1 / Simucube 2 Pro, Sport, Ultimate / VRS Direct Force Pro / OSW Small Mige, Large Mige/ Simagic Alpha

Updated 2021 Version

Some Customers have reported EMI from Fanatec wheelbases. If you are experiencing button press issues you will need to ground the dash to the wheelbase with the provided wire.

Step 1: Remove rear enclosure plate with 2mm Allen Key
Step 2: Take Wire and strip about 1 inch off. Route that wire to the wheelbase and wrap around the m6 bolt in between the rear of the dash and the front of the wheelbase as pictured below.
Step 3: Mount Dash as normal with wire between carbon plate and wheelbase</p>
If you need assistance please Contact Support</p>

Right Click and open in new tab or save image as to see full size
